Hayner PCB provides proudly LED PCB products with high-quality and low price. Our goal : lighting every inch of the world's land!

Hayner PCB Technology-World’s faster LED PCB manufacturer



Hayner PCB provides proudly LED PCB products with high-quality and low price. Our goal : lighting every inch of the world's land!



What is LED PCB


LED stands for light emitting diode. LED lighting products produce light up to 90% more efficiently than incandescent light bulbs.

LED PCB is a printed circuit board that connects LED chips and wires together. Its main function is to convert electrical energy into light energy, thereby achieving the luminous function of LED.



Advantage of LED PCB


The main Benefits of LED Circuit Boards is Reduced power consumption: LEDs use at least 75% less energy than incandescent bulbs.

Due to its advantages such as high brightness, low power consumption, and long lifespan, LED PCB has become the preferred material in the lighting field.




Applications of LED PCB


PCB circuit board isessential to many applications, one of them is LED lighting. LED PCB is the core of LED lighting.

PCB LED lights have excellent energy efficiency, low cost, and maximum design flexibility, making them suitable for many lighting applications.

1. Telecommunications: LED indicator lights and displays are always used in telecommunications equipment.

2. Automotive: Aluminum PCB LEDs are also used in automotive indicator lights, brake lights, headlights, and other applications.

3. Computers: LED displays and indicator lights are becoming increasingly popular in computer applications.

4. Medical: The lighting tools used in surgical procedures and medical examinations typically use high-power LED lights.



LED PCB Manufacturing and Assembly Capabilities


Specifications

Capability

PCB Material

FR-4, HI Tg, Rogers, Taconic, Argon etc.

PCB layer

1-30 layer

PCB types

single/double-sided, multi-layer

Copper Thickness

1-6oz

Board Thickness

S/D 0.2-0.7mm, Multi-layer:0.40-7.0mm

Surface finish

HASL,OSP,Immersion gold,Flash Gold Finger

Solder film

green,red, yellow,blue,white,black,purple,matte black, matte green

Screen printing

white, black

Min. Hole Size

0.2mm mechanical drill

4mil laser drill

Min.Line Spacing /

Min.Line Width

6mil

6mil

Min. Solder Mask Bridge

0.08mm

Max. Production Size

400x510mm

Impedance control

50Ω ±5Ω, 90Ω ±9Ω, 100Ω ±10Ω

Aspect ratio

15:1

Via Plugging Capability

0.2-0.8mm

PCB Standard

IPC-II Standard

Warp & Twist

0.75%

Certificate

ISO9001.IATF16949.RoSH.UL.

Quality Control

X-ray, AOI Test, Function Test (100% Test)

Delivery

PCB 3-7 Days, PCBA 2-3 weeks



Haina Lean Production Ability:


vSeven SMT production lines --10million points/day

vFour THT production lines ---  0.50million points /day

vThree Final assembly lines ----15,000pcs/day

vOne Aging room    -------------- 2,000pcs/day

vThree Spraying lines ------------- 3,000pcs/day



Hot Tags: LED PCB, China, Manufacturer, Supplier, Factory, Price, Cheap, Customized, In Stock
