Hayner PCB 's main product - High Tg PCB, manufactured in China by a leading manufacturer and supplier in the electronics industry, represents the pinnacle of quality and performance in printed circuit board technology. This advanced PCB features a high glass transition temperature (Tg), enabling it to withstand extreme temperatures without compromising its structural integrity or electrical properties.

Hayner PCB - advanced high-quality High Tg PCB manufacturer

The Hayner PCB 's main product - High Tg PCB, proudly manufactured in China by a seasoned manufacturer and esteemed supplier, showcases the pinnacle of quality and innovation in the field of printed circuit boards. Specially engineered with a high glass transition temperature (Tg), this PCB is designed to excel in environments where intense heat and rigorous operational demands are the norm. By utilizing premium materials and advanced manufacturing techniques, Hayner PCB ensures that every High Tg PCB is crafted to the highest standards of quality, ensuring long-term reliability and durability.


As a trusted supplier, Hayner PCB adheres to strict quality control protocols throughout the production process, from raw material selection to final inspection. This commitment to excellence results in PCBs that are dimensionally stable, capable of supporting high-frequency signals, and ensuring faster data transmission rates. Whether you're developing cutting-edge consumer electronics, complex industrial automation systems, or high-performance telecommunication networks, Hayner PCB 's main product - High Tg PCB is the perfect choice for your application, offering unparalleled performance and dependability.




What is High Tg PCB



The Tg in PCB circuit board refers to the temperature resistance value.

The higher the g-point, the higher the temperature requirement for pressing the plate, and the pressed plate will also become hard and brittle, which will to some extent affect the quality of mechanical drilling.

The general Tg film is above 130 degrees, High Tg is usually above 170 degrees, and the medium Tg is above 150 degrees. The Tg of the substrate has been improved, including heat resistance, moisture resistance, chemical resistance, stability, etc., and the functionality of the printed circuit board will continue to improve.

The higher the G value, the better the heat resistance of the board, especially in lead-free tin spraying processes where high T applications are more common.



Advantage of High Tg PCB



Temperature stability

High Tg boards can maintain stable size and shape over a wider temperature range, allowing PCBs to maintain good electrical performance even in extreme environments.


Heat resistance

High Tg materials usually have better heat resistance, which means that PCBs are less prone to warping or delamination during the welding process, improving the installation quality and reliability of components.



Dimensional accuracy

Due to the small deformation of high Tg sheets during heat treatment, they can maintain higher dimensional accuracy and are particularly suitable for precision electronic devices.



Long term reliability

Long term exposure to high temperature environments allows high Tg sheets to maintain their mechanical and electrical properties better than low Tg sheets, thereby extending the product's service life.




Applications of High Frequency PCB



1. Communication equipment: Used for devices that require high temperature and high frequency stability, such as wireless base stations and fiber optic communication equipment.

2. Automotive electronics: Used in automotive electronic systems, such as onboard computers and engine control units, as they require operation at extreme temperatures.

3. Industrial control equipment: Used for industrial automation and robots, it needs to withstand high temperature, humidity, and vibration.

4. Aerospace: Used for aircraft, satellites, and navigation equipment that need to withstand extreme temperatures and working conditions.

5. Medical equipment: Used for medical equipment that needs to operate under high temperature and high humidity conditions, such as medical imaging equipment.

6. Radar, such as radar systems and missile control, require extremely high reliability and high-temperature performance.





High Tg PCB Manufacturing and Assembly Capabilities


Specifications

Capability

PCB Material

FR-4, HI Tg, Rogers, Taconic, Argon etc.

PCB layer

1-30 layer

PCB types

single/double-sided, multi-layer

Copper Thickness

1-6oz

Board Thickness

S/D 0.2-0.7mm, Multi-layer:0.40-7.0mm

Surface finish

HASL,OSP,Immersion gold,Flash Gold Finger

Solder film

green,red, yellow,blue,white,black,purple,matte black, matte green

Screen printing

white, black

Min. Hole Size

0.2mm mechanical drill

4mil laser drill

Min.Line Spacing /

Min.Line Width

6mil

6mil

Min. Solder Mask Bridge

0.08mm

Max. Production Size

400x510mm

Impedance control

50Ω ±5Ω, 90Ω ±9Ω, 100Ω ±10Ω

Aspect ratio

15:1

Via Plugging Capability

0.2-0.8mm

PCB Standard

IPC-II Standard

Warp & Twist

0.75%

Certificate

ISO9001. IATF16949. RoSH.UL.

Quality Control

X-ray, AOI Test, Function Test (100% Test)

Delivery

PCB 3-7 Days, PCBA 2-3 weeks



Hayner PCB Production Ability:



Seven SMT production lines --10million points/day

Four THT production lines --- 0.50million points /day

Three Final assembly lines ----15,000pcs/day

One Aging room  -------------- 2,000PCS/day

Three Spraying lines
